It all started when...

I ordered the moto:bit from Sparkfun.

I wanted to build a robot for my daughter’s Girl Scout troop to play with. One thing I needed was a way to make the BBC Microbit’s sound functions audible to a room full of 9 year old girls. I didn’t find anything that was as small and loud as I wanted so I build my own.

Top: Sparkfun Redbot Buzzer – This was just the wrong part. It isn’t really designed to be a speaker.Middle: The first prototype – A dismal failure.Bottom: Success! – Loud and small.

Top: Sparkfun Redbot Buzzer – This was just the wrong part. It isn’t really designed to be a speaker.

Middle: The first prototype – A dismal failure.

Bottom: Success! – Loud and small.

Order from OSH Park

Below you see the v1 PCB, which was the dismal failure, retrofitted to prove the new speaker design for the next version. From there I breadboarded the LM48310 audio power amplifier circuit hooking it up to the PUI Audio AS02008MO-R speaker glued to this board.
